Brand story/Glorious brand is positioning:energy-saving,environmental protection,reliable and high-quality.We sell the products to abroad,at the same time,we undertake the engineering installation and service of project in China.We do our best to supply the system solution which is advanced technology,energy-saving,low operation charge and easy to maintain.

Glorious(Shenzhen) Ltd was established in Shenzhen by the headquarters that Glorious(HongKong) Ltd authorized.It got the authorization by the company headquarters, to produce the Glorious brand series products in China.
Glorious(Shenzhen) Ltd was established in May 1998,is a Comprehensive enterprise including research and development,produce,import and export,domestic sales、installation and After-sales service.In the past ten years,Glorious(Shenzhen) Ltd is always walk in the forefront of the industry in the fierce market competition,the products are hot sale in many countries . Glorious(Shenzhen) Ltd will continue innovation，taking the technology as the core,depending on the quality of life, to serve customers as god.We provide the users with "First-class products"、”Professional design”、” Perfect construction”、” Top services”.Leading the swimming pool industry into another peak.

Product introduction

			The heat pump water heater(units) was introduced the advanced technology of heat pump and we improved and optimized it on the base

The heat pump water heater(units) was introduced the advanced technology of heat pump and we improved and optimized it on the base, we use the heat pump compressor which is from the world famous factory ,and combined with our unique and professional design and manufacture.We push out the newest technology of energy-saving products which is synchronize with the aboard advanced technology and originated in China.

Characteristics

	High thermal efficiency,it can up to 580%,can get more air heat.
	The case is use contoured design,and the fan embed,make the appearance novelty and beautiful.
	Safety and environmental protection,No sewage emissions,and can provide free cool air.
	Easy to install and maintain,reliable quality and high degree of automation.
	Less floor space,and can be placed in the open area and weatherproof.

	Titanium heat exchanger,and against variety of chemical corrosion.
	With automatic low temperature defrost function
	Ultra-low temperature heat pump,suitable for working in low temperature(-15℃ can normal operation)
	Using microcomputer central control,through the heating of titanium heat exchanger to make the electrical and water strict separation.
	Equipped with multiple protection,without any security risks.

Technical Parameters

Performance parameter of Air-source heat pump for pool.
Item No		GL-PHP-5	GL-PHP-10
Current		380V/3Ph/50Hz	380V/3Ph/50Hz
Run Control		Manual, Automatic Turning, multiple protection and fault alarm function
Refrigerant		R404A	R404A
Refrigerant charge amount		2.8kg	5.6kg
Anti-electric shock Rate		CLASS I type	CLASS I type
Protection class		IPX4	IPX4
Maximum temperature of outlet		55℃	55℃
Circulating water flow		10m³/h	18m³/h
Air out way		air out from top	air out from top
Water-side pressure loss		18kpa	30kPa
Security Configuration		High / low pressure switch, winter frost protection, compressor over-current protection, compressor over-temperature protection, overload protection, reverse phase protection, leakage protection
The diameter of circulating water take over the pipe		DN40	DN50
Noise		≦65dB	≦65dB
Air out way		air out from top	air out from top
Fan power×number of		580W×1	900W×1
Dimensions		9267861090mm	1086976960mm
Net weight		150Kg	241.5Kg
Standard accessories		Installation instructions, warranty card, certificate
Temperature27℃	Output power KW	4.32	8.17
	Output power KW	23.0	47.9
	COP	5.3	5.8
Temperature20℃	Input power KW	4.36	8.21
	Output power KW	21.72	45.1
	COP	5.0	5.5
Temperature15℃	Input power KW	4.38	8.25
	Output power KW	20.5	42.48
	COP	4.7	5.1
Temperature10℃	Input power KW	4.4	8.29
	Output power KW	19.3	39.61
	COP	4.4	4.8
Temperature5℃	Input power KW	8.17	47.9
	Output power KW	5.8	8.21
	COP	45.1	5.5
Temperature0℃	Input power KW	8.24	42.48
	Output power KW	5.1	8.29
	COP	39.61	4.8
Temperature-5℃	Input power KW	8.33	37.67
	Output power KW	4.5	31
	COP	8.4	3.7
Temperature-10℃	Input power KW	8.5	26.5
	Output power KW	3.1	8.5
	COP	19.4	2.3
