High temperature protection switch makes motor stop running automatically on abnormal conditions. |
|
|
Waterproof and dustproof standard meets IP56-class. |
|
|
F-class insulation , motor can be in motion constinuously and reliablely under 75℃. |
|
|
Plastic cooling fans resistant to high temperature. |
|
|
Engeneering plastics pump resistant to high tempreture,good-hardness and durable. |
|
|
Hydraulic model with excellent design is large flow, high effciency and more energy saving. |
|
|
Imported low noise bearings and meachanical seals are quiet runing and long-time sealing, long working life. |
Product Parameters
| Model No | Output Power（KW） | Voltage（V） | Power factorcosΦ | Current（A） | Rotational Speed（r/min） | H(mm) | L(mm) | W(mm) | Weight（kg） |
| RS-MP-15 | 0.55 | 220-240 | 0.9 | 3.5 | 2860 | 255 | 330 | 238 | 10 |
| RS-MP-25 | 1.1 | 220-240 | 0.9/0.95 | 7 | 2860 | 265 | 369 | 238 | 15 |
| RS-MP-50 | 1.6 | 220-240 | 0.9 | 10 | 2860 | 271 | 330 | 238 | 22.3 |
| RS-MP-15/50 | 0.3/1.6 | 220-240 | 0.95 | 2.7/10 | 1420/2820 | 271 | 369 | 238 | 21.8 |
